Tridonic 2 x 58W PC T8 Pro High Frequency Ballast

BALLAST 2x58w T8 PRO SI PC PRO sl Digital 220-240v 50/60Hz TRIDONIC (22185218TR)

The Tridonic PC2X58T8TEC is an electronic ballast that will run both 2 x 58w T8 fluorescent tubes and 2 x 55w TCL compact fluorescent. It is not dimmable.

Product Overview

• Lamp Type: T8 fluorescent
• Lamp Wattage: 2 × 58W
• Input Voltage: 220–240 V AC / 198–264 V DC
• Frequency: 50/60 Hz (also supports 0 Hz for DC operation)
• Power Factor: >0.98
• Circuit Power: ~50–54.5 W per lamp
• Current at 50 Hz: ~0.26 A (220 V) / ~0.24 A (240 V)
• Operating Frequency: ≥39.5 kHz
• Warm Start Time: ≤1.5 seconds
• Dimensions: 280 mm (L) × 30 mm (W) × 28 mm (H)
• Weight: ~0.216 kg
• Fixing Centres: 270 mm
• Protection Class: IP20
• Ambient Temperature Range (ta): -25°C to +60°C
• Maximum Case Temperature (tc): 75°C

Key Features

• nergy Efficiency: CELMA EEI = A2 BAT
• SMART-Heating Technology: Enables ≥50,000 starts without lamp replacement
• Intelligent Voltage Guard: Overvoltage indication and undervoltage shutdown
• End-of-Life Protection (EOL 2): Safe shutdown of defective lamps
• Automatic Restart: After lamp replacement
• Emergency Lighting Compatibility: EN 50172 compliant
• IDC Terminals: For fast and secure wiring
• Non-Dimmable: Fixed output only
• Long Life: Up to 100,000 hours at 50°C with <0.1% failure rate per 1,000 hours
